Delivery Room Furniture

Description

Delivery Bed (Three Section)

• Dimensions : 1830 L x 550 W x 800 H mm.
• Tubular pipe framework in three section.
• Upholstered top on wooden ply-board.
• Mounted on PVC/Rubber stumps.
• Head and Foot sections adjustable on ratchet.
• Perineal ‘U’ shaped cut in leg section.
• Provided with padded lithotomy crutches with ball & socket joint with adjustment for knee rest, shoulder support, hand grip and SS bowl.
• Pre-treated & Epoxy powder coated.

Obstetric / Gynae. Labour Table

• Size : 1830 x 760 x 760mm Ht.
• Complete stainless steel sheet top.
• Provided with manual head low attachment.
• Top frame made from ERW tube.
• Stainless steel IV pole with telescopic IV rod.
• Provided with a pair of lithotomy bars with belts.
• Pre-treated and epoxy powder coated.
• Table can be optionally provided with water proof laminated board instead of stainless steel top
• Also available complete in Stainless Steel version.

Gynae Examination Table

• Size 72” L x 27” W x 30” H
• Tubular frame work mounted on PVC stumps.
• Upholstered top in two section.

Birthing Bed Motorized

• Overall Approximate Dimensions  2050 MM (L) X 1020 MM (W)
• Minimum Height  490 mm (Without Mattress)
• Maximum Height  780 mm (Without Mattress)
• Detachable ABS Head and Foot Boards.
• Collapsible ABS Guardrails.
• 125mm Double Wheel Castors (two with Brakes)
• Electrical Lifting system with (Taiwan) Motors. (2 Year Warranty)
• Bed Framework made from mild steel ERW rectangular tubes.
• Bed top made from Nonmagnetic Bakelite sheet. X-Ray Compatible.
• Trendelenburg & Reverse Trendelenburg.
• Telescopic leg section that reduces the overall length of the bed,  allowing maximum access to mother & baby.
• Comprehensive range of easy to fit accessories including stirrups leg rests, hand grips, high and low foot supports for accessories step and a fluid collection bowl.
• Bright, modern appearance

Obstetric Labour Table (Hydraulic)

• Overall Size : 1870 L x 680 W x 760 to 900 mm
• Movement Controlled by Single Action hydraulic pump to achieve smooth and efficient operation without any jerks. Table is mounted on castor wheels with brake.
• Table top in three sections. Back rest adjustable on ratchet.
• Middle section with U cut & leg section can slide completely under main frame.
• The whole top can be tilted to trendelenburg position with the help of Lever Handle.
• Standard Accessories Lithotomy rod, Hand grip, Railing on head and sides, Stainless Steel bowl and mattress in three part.
• Pretreated and epoxy powder coated.

Hydraulic Delivery Table

Movement Controlled by Single Action hydraulic pump to achieve smooth and efficient operation without any jerks. Table is mounted on castor wheels with brake Table top in three sections. Back rest adjustable on ratchet. Middle section with U cut & leg section can slide completely under main frame. The whole top can be tilted to trendelenburg position with the help of Lever Handle. Standard Accessories Lithotomy rod, Hand grip, Railing on head and sides in EPC, Stainless Steel bowl and Rubber mattress.

Size:  1870 L x 680 W x 760 to 900 mm

Delivery Bed

Leg section approx: 930L x 640mm. Bed labour and deliver mainly made of mild steel. Bed top in two sections, body section mounted on rubber stumps and legs section mounted on two castors with brake, Legs section can be completely recessed under the body section Mattress 60mm thick foam covered with water proof synthetic material. Table consisting of pair lithotomy poles with strip or knee pad & stainless steel bowl arrangement underneath of leg section. Finish in epoxy powder coated.

Size: Body section approx 1000 L x 770 W x 760 mm

Gyne Table (Three Section)

Constructed for ms tubing. Adjustable head and leg section Meddle section movement by mean of a hand crank. Top is upholstered and covered with cushioned. Complete with Bowl 32 cm dia. and two adjustable legs rest. Finish in epoxy powder coated. Also available in complete stain steel

Size: 1830 L x 600 W x 800 H mm

Delivery Table

Constructed from ms rectangular steel tube. Adjustable head section. Leg section movable on castors, two with brakes. Top is upholstered and covered with water proof synthetic material. Complete with SS bowl 32 cm. Dia., Standard padded leg holders. Finish in epoxy powder coated.

Size: 1830 L x 610 W x 800 H mm

Operation Table

Table top is made of strong ms steel framework with SS sheet top. The whole top can be tilted to trendelenberg and reverse trendelenberg with help of lever handle. Table legs of ERW tubing mounted on 10 cm dia swiveling castors with two breaks. The table is complete with following accessories: chrome plated litholomy rod and anesthesia screen. SS kidney bridge and arm board finish in Epoxy powder coated.

Obstetric Labour Table

Table top in three section made of strong steel frame work. Backrest adjustable on ratchet The whole top can be tilted to trendelenberg position with the help of lever handle. Conversion is easily and simply performed by sliding the leg section. Table consisting of meddle section of stainless steel. The table is complete with the following accessories: chrome plated lithotomy rod, hand grip, saline rod, side& head railing, stainless steel bow.

Size: 1870 L x 680 W x 800 H mm
