Microscopes

Binocular Microscope
Monocular Microscope
Projection Microscope
Stereoscopic Zoom Binocular Microscope
Tissue Culture Microscope
Trinocular Microscope

Note: Pictures shown are indicative only and the actual product may vary.

Select the chosen product and click Add To Quote

Microscopes

Clear

SKU: N/A Category: Laboratory Equipment

Description

Binocular Microscope

Binocular microscopes provide better images and are good for long-time observation. Binocular microscopes have two eye-tubes. Binocular microscope is easy-to-use microscopes which comes equipped with a binocular head. The binocular microscope is especially useful for use in the medical field, lab work, and any educational institute. Binocular research microscopes are of ergonomic design suitable for most applications in transmitted light microscopy. This model display a state of the art understanding of operator requirements and comfort. The quadruple revolving nosepiece is carefully positioned so that it face inward and objectives pointing away from the user so that they will not interfere with operator. It is equipped with CF contrast LB objectives having monolayer coatings to reduce internal reflection, thus ensuring high contrast image.

Specification:

Observation head.	Binocular head is equipped with standard 450 inclined observation tubes, rottable through 3600 and can be fixed in any direction with clamp screw, interpupillary distance from 53 to 75mm & diopter adjustment are provided.
Stand	One piece die cast arm and large size rectangular, heavy stable base with transformer/electrical fittings concealed inside.
Nosepiece	Precise quadruple revolving nosepiece with accurate centering and positive click stops for smooth accurate rotation.
Stage	built in graduated mechanical stage size 135×120 mm is controlled by convenient low co-axial positioned knobs (either side as per requirement) for easy and smooth scan of the specimen slide over entire range of 50 x 75 mm.
Focussing	By vertical movement of stage, coarse adjustment by rack pinion and fine movement by screw lever mechanism having a graduated knob
Illumination	6V-20W Halogen lamp fitted directly under the field lenses operated through solid state variable controlled transformer 220 or 110 volts. Mirror attachment while working in day light is also provided
Objectives	Achromatic 4x – 10x – 40x sL and 100 XSL oil immersion.
Eyepiece	Wide field WF10X and H5X or H6X or H15X (any two pairs)
Packing	In full mould Styrofoam / Thermocol container.
Accessories	Vinyl cover, duster, cleaning brush, filter & Operating Manual.
Optional Accessories	Dark-field condenser, phase contrast equipment, polarizing attachment, stage micrometer, micrometer discs, spare objectives, micro photographic equipment and CCTV, wooden storing cabinet etc.

Application:

Monocular Microscope

Microscopes are primarily employed to produce enlarged images of small object. Monocular Microscope consists of only one lens. Monocular microscopes are built from high quality materials producing high quality enlarged image offering higher degree of resolution.It is equipped with higher achromatic objective lens, white fluorescent illumination system, high quality LED illuminator with advanced technology and ergonomic design.

Specifications:

Stand	Stable and Robust, assembled from Aluminum DIE-CAST parts.
Body	Monocular tube inclinable up to 900, Mechanical Tube length 160 mm.
Stage	Built in horizontal graduated mechanical stage size 120×120 mm with convenient adjustment for slide manipulation upto 40×75 mm.
Nosepiece	Quadruple revolving nosepiece with positive centering & click stops.
Condenser	Bright field, Abbe N.A. 1.25 with iris diaphragm and swing out filter holder can be moved through rack pinion. The condenser unit incorporates high efficiency optical system for optimum utilization of light from low to high magnification.
Focussing	Separate knobs are provided for coarse and fine focusing adjustments. Coarse adjustment can be made through Rack-Pinion and fine movement by screw lever mechanism having a graduated knob on the right side.
Safety Device	Adjustable down stopper for preventing accidental damage to slides.
Illumination	Plano concave mirror diameter 50 mm gimble mount.
Objectives	Achromatic 10x40xSL and 100x SL oil immersion.
Eyepieces	Huy. 5x – 6x- 10x – 15x (Any two) or WF 10x.
Accessories	Vinyl cover, duster, cleaning brush, filter & operating manual.
Packing	In full mould Styrofoam / Thermocol container.
Optional Accessories	Co-Axial mechanical stage, wooden storing cabinet with lock and key.tube, spare objectives, sub-stage 20W Lamp for 220/110V.

Applications:

Biology
Biotechnology
Microbiology
Biochemistry
Zoology
Schools And Colleges
Research

Projection Microscope

An advanced versatile projection microscope for measurement of specimens, different types of yarns in textile industries and research institutes. It is equipped with Halogen bulb of 12V/100 watt workable through a solid state built in transformer working on 220V AC mains.

Features:

Condenser: A high quality glass condenser in front of screen.
Mechanical Tube: Length 160 mm
Nose piece: Triple revolving nose piece.
Movement: Coarse motion through rack and pinion with precise and accurate fine movement. Fixed square stage 102 x 102 mm.
Lamp Assembly:Fixed lamp, built in base of high illumination with high power condenser and screen it will work as micro view projector.With lamp, transformer, but without it will work as microscope.The viewing of biological microscope slides is distinct and enlarged. Sharp, clear and evenly illuminated image in full colors, visible to the whole class free of distortion. Supplied in polished wooden box having lock and key.

Specifications:

Stereoscopic Zoom Binocular Microscope

Stereoscopic Zoom Binocular Microscope offers high point, lockable eyepieces and ergonomically located zoom control. Application areas include industrial and medical, Pathology and forensic applications. The microscope comes with versatile illumination system that provides both incident (top) lighting and transmitted (bottom) illumination. This microscope offers crystal clear sharp stereo images, large zoom magnification range and large working distance. Its 45° inclined binocular head ensures an easy observation and rubber eye guards provide further comfort. This microscope is great for the exploration of the world of surface details and fine structures of various materials like wood, metal, solder, semiconductor and gemstone. It is perfect for the examination of insects, plants, rocks, stamps, jewel, soldered points, microelectronic components, circuit boards or virtually any three dimensional objects.

Features:

Multi-Coated Optics
Two Wide Field Eyepieces
Two Objective Lenses (allow to see close things in 3D)
Solid Metal Construction
Rack and Pinion Focus Mechanism
One Year Warranty

Specifications:

Observation head.	Binocular head is inclined at 450 rotatatedthrough 3600 and can be looked in any position by using thumb screws.The interpupilary distance is adjustable between 55 to 75mm and right eye tube has dioptric focussing adjustment.
Objective	The microscope has a set of two standard objectives 2x & 4x. the low & high powered objectives are selected by rotating the nosepiece through 900, having parfocal magnification.
Eyepieces	The standard extra wide field eyepieces WF 10X is provided
Magnification	Standard magnification 20x & 40x with flat field.
Image	Erect, three dimensional, crisp and sharp image.
Focusing	By rack and pinion mechanism with adjustable tension collar.
Illumination	With integral illuminator, two lamps are fitted to provide both transmitted & incident illumination. The lamps can be switched on separately or together. Complete with a glass plate having two stage clips.
Power Supply	22V-240V AC or 110V-120V AC, 50-60 Hz.
Accessories	Vinyl cover, dust cover, duster & cleaning brush .
Packing	In wooden storing cabinet with lock & key.
Optional Accessories	An array of different stands, stages and attachments designed to fit a variety of specific requirements. Choice of two objective combination 1x-2x or 1.5x-3x. spare eyepieces WF10X and dark field attachment

Tissue Culture Microscope

Working with live cells involves providing some sort of medium to facilitate the growth of these cells. Whether this involves petri dishes or some other vessels, this necessitates a live cell microscope (tissue culture cell microscope) that will accommodate them. It also requires microscope objective lenses with longer working distances to be able to focus on the live cells through the bottom of these vessels.Tissue culture microscopes can provide any combination of modalities for live cell work including brightfield, phase contrast, and fluorescence, or any combination of these modalities.Specifications:

Viewing Head	Trinocular Head Inclined at 30°
Eyepiece	Extra Wide Field Eyepiece EW 10X
Objective	LWD Infintive PLAN Objective 4X, LWD Infintive PLAN Objective 40X, Infinitive PLAN PHASE Objective PH 10X, Infinitive PLAN PHASE Objective PH 20X,
Nosepiece	Quintuple Nosepiece
Condenser	ELWD Condenser NA 0.3. LWD 72mm, (Without Condenser 150mm)
Phase Annulus	10X-20X Phase Annulus Plate
Stage	Plain Stage 160x250m, Glass Insert, Auxiliary Stages 70x180mm
Focusing	Coaxial Coarse and fine adjustment.
Illumination	Halogen Lamp 6V 30W
Filter	Blue, Green and Ground Glass
Dimension	48 x 41 x 67cm. Approx
Weight	12 Kg Approx.

Trinocular Microscope

A Trinocular microscope is equipped with three eyepieces to offer better resolution of the product image. Trinocular microscope comes with continuous adjustable magnifications. Trinocular port enables the addition of photographic or video capability. With super wide field, high-eye point eyepieces, it gives sharp and crystal clear images with high resolution. It offers large zoom ranges and long working distances.

A line of eleven Plano-apochromatic objectives (long and super-long working distances models available) is designed for use in the visible wavelengths. They are corrected for chromatic aberration in the red, yellow, and blue, and provide good color reproducibility.

Features:

The Trinocular microscopes have a built-in transmitted illumination system.
The precise focusing mechanism allows both coarse and fine focus adjustments, to yield crisp, clear images. Imaging is also aided by a fiber optic light guide that provides bright field illumination.
The 50/50 Trinocular microscope head allows for simultaneous video and binocular viewing. The focusing 10X or 20X wide field eyepieces can accept 25-mm diameter reticules for measurement applications.
The reverse nosepiece can hold up to four objectives, allowing a range of magnifications. The instrument has a 1X to 2X zoom range.
The objectives are available in a range of magnifications from 2X (with a numerical aperture (NA) of 0.055 and a working distance of 34 mm), to 200X (with a NA of 0.62 and working distance of 13 mm).

Specifications:

Observation head.	Trinocular Head is equipped with standard 450 inclined observation tubes,rotatable through 360 and can be fixed in any direction with a clamp screw. Interpupillary distance from 53 to 75 mm & diopter adjustment are provided. Right hand slide lever provides 100% light to binocular head or vertical photo tube.
Stand	One piece die cast arm and large size rectangular, heavy stable base with transformer/electrical fittings concealed inside.
Nosepiece	Precise quadruple revolving nosepiece with accurate centering and positive click stops for smooth accurate rotation.
Stage	built in graduated mechanical stage size 135×120 mm is controlled by convenient low co-axial positioned knobs (either side as per requirement) for easy and smooth scan of the specimen slide over entire range of 50 x 75 mm.
Focussing	By vertical movement of stage, coarse adjustment by rack pinion and fine movement by screw lever mechanism having a graduated knob
Illumination	6V-20W Halogen lamp fitted directly under the field lenses operated through solid state variable controlled transformer 220 or 110 volts. Mirror attachment while working in day light is also provided
Objectives	Achromatic 4x – 10x – 40x sL and 100 XSL oil immersion.
Eyepiece	Wide field WF10X and H5X or H6X or H15X (any two pairs)
Packing	In full mould Styrofoam / Thermocol container.
Accessories	Vinyl cover, duster, cleaning brush, filter & Operating Manual.
Optional Accessories	Dark-field condenser, phase contrast equipment, polarizing attachment, stage micrometer, micrometer discs, spare objectives, micro photographic equipment and CCTV, wooden storing cabinet etc.

Additional information

Microscopes	Binocular Microscope, Monocular Microscope, Projection Microscope, Stereoscopic Zoom Binocular Microscope, Tissue Culture Microscope, Trinocular Microscope

Reviews

There are no reviews yet.

Be the first to review “Microscopes”

Microscopes

Description

Additional information

Reviews

KEEP UPDATED

Visit LSP

Head/Screen	Grain less Optical true 150 mm outer circular dome, 360° rotatable for mounting on microscope.
Eyepiece	X10 Huygenian
Objective	X10 and X40 spring loaded
Stand	Rigid, improved styled base, body fixed with the base all movements provided with the stage to lesser wear and tear.
